Automatic Transfer Switch KS ATS 4/25 Gasoline

Automatic Transfer Switch KS ATS 4/25 Gasoline

Name: Automatic Transfer Switch KS ATS 4/25 Gasoline
Brand: Könner & Söhnen
SKU: 4260405364787
Price: 269.0 EUR
Availability: InStock

Available

€269,00

Specification

Working environment:	from -10°C to +55°C; humidity: ⩽60%
Voltage, V:	230/400

Benefits

Versatile design for use in both single-phase and three-phase networks
Automatic or manual control mode makes the system more user-friendly
Emergency stop button is used to turn off the generator to prevent damage to the generator or connected devices
Maintains the battery in a charged state
5-meter control cable allows you to position the device at a convenient distance

Delivery

Free shipping: receive your order in just 1-5 business days.

Payment

We offer a wide range of secure and convenient payment methods, including:

Features

The KS ATS 4/25 Gasoline ATS (Automatic Transfer Switch) unit from the German brand “Könner & Söhnen” automatically starts the generator and transfers load to it when the main power source is turned off and automatically stops the generator when the central power supply is restored. It is compatible with gasoline inverter generators that are equipped with a 8-pin connector for an automatic transfer switch unit (ATS input). The ATS unit has a PLC for programming the engine starting time after power outage, the engine warm-up time before connecting power consumers as well as for signaling errors. It has a generator emergency stop button. The ATS unit can operate both in automatic and in manual mode.

PROGRAMMABLE LOGIC CONTROLLER OF THE ATS UNIT:

Automatic/manual operation
Programming of engine starting time after power outage
Programming of engine warm-up time before connecting to consumer
Setting of starter operation time
Engine performance monitoring
Battery charging when the generator is off

The KS ATS 4/25 Gasoline ATS unit is compatible with Könner & Söhnen gasoline inverter generatorsKS 4000iE S, KS 4100iE, KS 6000iE S, KS 8100iE ATSRwith integrated 8-pin ATS connector.

Specification

Automatic Transfer Switch KS ATS 4/25 Gasoline

Peak power demand, W	in standby mode: 0.36 W, in operating mode: 1.2 W
Power (230V), kW	5.75 (11.5)
Current (max) 230 V, A	25(50)
Power 400V, kW	13
Current (max) 400 V, A	25
Working environment	from -10°C to +55°C; humidity: ⩽60%
Storage environment	from -10°C to +70°C; humidity: ⩽60%
Insulation class	AC1.0KV / 1min 1mA
Maximum battery charging current from the built-in power supply, A	2
Control cable length, m	5
Voltage, V	230/400
IP protection class	IP41
Net dimensions (LxWxH), mm	250 х 140 х 320
Gross dimensions (LxWxH), mm	325 х 200 х 405
Net weight, kg	6
Gross weight, kg	6.5
SKU	KS ATS 4/25 Gasoline
Barcode	4260405364787
